pptx-vue-viewer

pptx-vue-viewer

Show, edit, and present Microsoft PowerPoint (.pptx) files directly in a Vue 3 app: no server, no conversion step, no PowerPoint install required. Drop in a <PowerPointViewer> component, hand it the file's bytes, and it renders slides as real HTML and CSS with full editing and export support.

The rendering is done by the framework-agnostic pptx-viewer-core engine, which turns a .pptx file into a structured slide model. This package is the Vue layer that draws that model on screen, and the engine is bundled in, so you install just one package.

▶️ Try the live demo · 📦 npm · 📖 Full docs · 🧩 Core SDK

Part of ooxml: Office · Word · Excel · PowerPoint · Visio · OpenTeams · Core

Features

• A single component: <PowerPointViewer>, written in <script setup> style.
• Real HTML rendering: slides are drawn as ordinary HTML and SVG, not as a picture, so text stays sharp at any zoom and is selectable and accessible.
• Editing: select, drag, resize, rotate; inline text editing; format painter; shape adjustment handles; align, distribute, group, flip, and z-order; undo/redo; snap-to-grid, snap-to-shape, H/V guides, and rulers.
• Full Office-style ribbon: all tabs wired (Home, Insert, Draw, Design, Transitions, Animations, Slide Show, Review, View) plus a status bar and context menu.
• Inspector: element and slide property panels, including chart data editor.
• Presentation mode: animation playback, presenter view, slide transitions, rehearse timings, subtitles, and freehand ink.
• Export: PNG, PDF, GIF, and WebM video; print; Save As (pptx/ppsx/pptm).
• Collaboration: real-time Yjs-based co-editing with cursor/selection presence.
• Comments, find/replace, accessibility panel, version history, and more.
• Mobile chrome: touch toolbar, bottom bar with sheets, and touch editing.
• Slide navigation: live thumbnail previews, previous/next, and a slide counter.
• Zoom: in, out, and reset.
• Themeable: change colours through CSS custom properties.
• Loads from anywhere: an ArrayBuffer or Uint8Array from a file input, a fetch, drag-and-drop, and so on.

Installation

npm install pptx-vue-viewer

Peer requirements: Vue 3.5+, vue-i18n (all UI labels go through it, see Localization), and the engine's jszip / fast-xml-parser peers:

npm install vue vue-i18n jszip fast-xml-parser

Optional: three enables interactive GLB/GLTF 3D models and the smartArt3D and 3D chart renderers; without it those elements fall back to poster images / flat SVG.

The pptx-viewer-core engine is bundled in, so you don't install it separately unless you want to call the SDK directly.

Usage

<script setup lang="ts">
import { ref, onMounted } from 'vue';
import { PowerPointViewer, type PowerPointViewerExpose } from 'pptx-vue-viewer';

// Base chrome styles (toolbar, thumbnails, layout). Import once.
import 'pptx-vue-viewer/styles';

const content = ref<Uint8Array>();
const viewer = ref<PowerPointViewerExpose>();

onMounted(async () => {
	const res = await fetch('/example.pptx');
	content.value = new Uint8Array(await res.arrayBuffer());
});

function onSlide(index: number) {
	console.log('active slide', index);
}
</script>

<template>
	<PowerPointViewer
		v-if="content"
		ref="viewer"
		:content="content"
		:theme="{ colors: { primary: '#6366f1' } }"
		@active-slide-change="onSlide"
		style="height: 100vh"
	/>
</template>

Loading from a file input

<script setup lang="ts">
import { ref } from 'vue';
const content = ref<ArrayBuffer>();

async function onFile(event: Event) {
	const file = (event.target as HTMLInputElement).files?.[0];
	if (file) content.value = await file.arrayBuffer();
}
</script>

<template>
	<input type="file" accept=".pptx" @change="onFile" />
</template>

Theming

Pass a partial theme; unset tokens fall back to the built-in dark palette. Values accept any CSS color (hex, rgb(), hsl(), oklch(), …) and map to --pptx-* CSS custom properties (shadcn/ui token names).

import type { ViewerTheme } from 'pptx-vue-viewer';

const theme: ViewerTheme = {
	colors: { primary: '#6366f1', background: '#0b1020' },
	radius: '0.5rem',
};

For app-wide theming you can also provide a theme to a subtree:

import { provideViewerTheme } from 'pptx-vue-viewer';
// call inside a parent component's setup()
provideViewerTheme({ colors: { primary: '#6366f1' } });

Two ready-made presets ship with the package: vermilionLightTheme (warm paper canvas) and vermilionDarkTheme (dimmed presenter room), the same vermilion brand look as the documentation site:

import { vermilionLightTheme } from 'pptx-vue-viewer';
// <PowerPointViewer :theme="vermilionLightTheme" … />

The underlying palettes (vermilionLightColors, vermilionDarkColors) and radius (vermilionRadius) are exported too for deriving your own variant.

Reading the current presentation back

getContent() turns the current presentation back into .pptx bytes. Reach it through a template ref:

const viewer = ref<PowerPointViewerExpose>();

async function save() {
	const bytes = await viewer.value!.getContent();
	// write `bytes` (Uint8Array) to a Blob / download / upload
}

Viewport fit options

<PowerPointViewer :content="content" :fit-padding="0" :max-fit-scale="null" />

fitPadding is a per-side CSS-pixel number or { horizontal, vertical }; maxFitScale is a positive fit-factor ceiling or null for unlimited enlargement. Omission preserves 8 px horizontal / 16 px vertical padding and a ceiling of 1. The same props are available on SlideCanvas. Rulers reserve their existing space separately. These options do not change document geometry or user zoom. See the cross-binding defaults.

API

Props

Events

Exposed methods (template ref)

The exposed surface implements the full shared PowerPointViewerAPI, so the following slide/element manipulation methods are also available: setActiveSlideIndex(index), getSlides(), getSlide(index), getActiveSlide(), addSlide(afterIndex?), deleteSlides(indexes), duplicateSlides(indexes), moveSlide(from, to), toggleHideSlides(indexes), getElements(slideIndex?), getElementById(id, slideIndex?), addElement(element), updateElement(id, patch), deleteElements(ids), and duplicateElement(id).

See element insertion for the addElement contract and a core-factory example.

Exported components & helpers

PowerPointViewer, SlideCanvas, SlideStage, ElementRenderer, RibbonToolbar, provideViewerTheme, useViewerTheme, and the ViewerTheme / CanvasSize / CollaborationConfig / ToolbarActionId / RibbonProps types.

Composing a custom viewer shell

For host-owned collaboration, useCollaboration accepts a reactive collaboration getter or shallow ref and exposes shellState: effective canEdit, connection status, sanitized remote users and connected count. Use it for both custom controls and their edit handlers. The public /viewer entry also exports InlineTextEditor and useInlineEditing for reusing the native inline editing behavior. See the custom-shell collaboration guide and demos/demo-vue/src/HostOwnedHeadlessEditor.vue for complete wiring.

<PowerPointViewer> bundles the slide canvas, ribbon, inspector, and every dialog into one component. If you only want a subset, for example your own chrome around just the ribbon and the slide canvas, import the pieces independently instead: RibbonToolbar (from pptx-vue-viewer, same as SlideCanvas) and the useRibbonProps composable (from the internal building-blocks entry point pptx-vue-viewer/internals) that assembles its props. The internals subpath is not covered by semver; prefer the stable root exports, and pin your version when relying on internals.

Most of that cross-framework logic (colour/geometry/connector/animation/chart math, slide transitions, and more) actually lives in pptx-viewer-shared, an internal package that is never published to npm. If you need one of those framework-neutral helpers directly, for example the slide-transition resolver/keyframes (resolveSlideTransition, resolveTransitionDurationMs, SLIDE_TRANSITION_KEYFRAMES) or the PresentationTransitionOverlay component behind presentation mode, they are re-exported from pptx-vue-viewer/internals too, so you never need pptx-viewer-shared yourself.

<script setup lang="ts">
import { SlideCanvas, RibbonToolbar } from 'pptx-vue-viewer';
import {
	useRibbonProps,
	useEditorHistory,
	useSelection,
	// ...plus whichever other composables you need to build the
	// `UseRibbonPropsInput` state/action fields (see ribbon-props-types.ts).
} from 'pptx-vue-viewer/internals';

// Wire up just the state/handlers your custom shell needs; anything from
// `UseRibbonPropsInput` you don't use can be a no-op ref/callback.
const ribbonProps = useRibbonProps({
	/* ribbonMode, canEdit, isMobile, ..., see UseRibbonPropsInput */
});
</script>

<template>
	<div class="my-custom-shell">
		<RibbonToolbar v-bind="ribbonProps" />
		<SlideCanvas :slide="activeSlide" :scale="zoom" />
	</div>
</template>

RibbonToolbar's full prop contract is the RibbonProps type; useRibbonProps returns a ComputedRef<RibbonProps> built from the same state/action composables PowerPointViewer.vue itself uses, so v-binding it straight onto RibbonToolbar mirrors the bundled component's wiring exactly.

Localization (i18n)

UI labels go through vue-i18n with dotted keys such as pptx.statusBar.allSaved. Create a vue-i18n instance with createI18n() and install it as a plugin (the demo's src/i18n.ts shows a minimal config, including a missing handler that derives Title Case labels for any key you don't explicitly translate):

import { translationsEn, keyToLabel } from 'pptx-vue-viewer/i18n';
import { createI18n } from 'vue-i18n';

const i18n = createI18n({
	legacy: false,
	locale: 'en',
	fallbackLocale: 'en',
	messages: { en: translationsEn },
	missing: (_locale, key) => keyToLabel(key),
});

Switch languages with i18n.global.locale.value = 'fr'. pptx-vue-viewer/i18n also exports a TranslationKey type for type-checking a new locale dictionary (Record<TranslationKey, string>) at compile time. See the Localization guide for the full picture across all five viewer bindings and how to contribute a translation upstream; the live demo's language picker is a working reference.

Limitations

A handful of effects (backdrop-filter, path gradients) are approximated on screen, and a few effects flatten in raster export; see the root README's Limitations for details.

The pptx-viewer-core engine parses all slide data, so anything not surfaced in the UI is still readable from the model.

Build (contributing)

bun run build      # Vite library build → dist (ESM + CJS + d.ts)
bun run typecheck  # vue-tsc
bun run test       # vitest

Reference translations

Optional French, Spanish, German, and Simplified Chinese dictionaries ship with this package. Import only the language you need:

import { translationsZhCN } from 'pptx-vue-viewer/i18n/zh-CN';

The other subpaths are i18n/fr (translationsFr), i18n/es (translationsEs), and i18n/de (translationsDe). See the localization guide for registration and runtime switching. Existing English imports are unchanged.

For Vue, convert the dictionary with toVueI18nSyntax from pptx-vue-viewer/i18n before passing it to vue-i18n.

License

Apache-2.0. Please keep the NOTICE file with redistributions.
